Corneal Analysis - Eye Measurement

Upload Slit-Lamp Image

Preview

Choose a slit lamp image, drag it here or paste it.

Scroll to zoom in/out and hold Option/Alt to grab and move

Pinch to Zoom in/out and use 2 fingers to move

Set Eye Board Units

Horizontal W-W

Sim K1

Sim K2

Control Center

Instructions

1. Draw the outline of the shape. 2. Drag the control points to edit the shape if needed. 3. Press Add Shape to add another shape.

Toggle Haze

Center of Measurement

Point Tap a point to set it as the angle reference	Distance (mm)Arc Distance	Angle (°) (CCW)Counter Clockwise	Angle (°) (CW)Clockwise	Actions

Spherical Polygon	Surface Area (mm²)Spherical Polygon Area	Actions

Clear Canvas Confirmation

Are you sure you want to clear canvas ?

Export

Please provide the patient's information

Patient Name

Patient ID

Eye

Right Left

INFORMATION

CornealAnalysis.com allows eye specialists to measure the coordinates and surface area of points and lesions on the cornea starting from a slit lamp photo.

About us

This website and online software is created and designed by:

Shady Awwad, MD: Founder.
Dr. Awwad is currently a staff physician and the head of the Cornea & Refractive Surgery Division at the American University of Beirut, Lebanon. www.DoctorAwwad.com

Jad F. Assaf: Project Development.‎
Jad is currently a medical student at the American University of Beirut, Lebanon. His interest and research is focused on biomedical analytics, namely corneal imaging and corneal tomography.‎

Special thanks to Andre Ghosn (Software Engineering), Pierre Chidiac (Mathematical Modeler), and Lily Chacra, MD (clinical application).

Disclaimer

CornealAnalysis.com is merely a tool to help the clinician better assess a clinical situation and plan an intervention. It cannot replace your clinical judgement. The authors take no responsibility in whatever clinical consequence that might ensue where this software is used.

Copyright

Unless otherwise indicated, copyright of all contents of this website is held by Dr. Shady Awwad. Material may not be used without prior consent.

INFORMATION

HELP

Do you want to be able to compute information from slit lamp photography? Like the size of a pterygium or epithelial defect or ulcer for subsequent follow up? The exact angle of a rotated toric intraocular lens? How about the chord kappa and alpha?

Finally, be able to delineate a corneal lesion and input the coordinates of the boundary points in a dedicated excimer software to perform customized ablation area phototherapeutic keratectomy (PTK). Many other clinical applications are available, your imagination and clinical sense are the limit.

Step-by-step tutorial

Simply snap a photo of any lesion using a smartphone hooked to a slit lamp, or from any slit lamp photography, upload it to the cloud using any popular service like one drive, Dropbox, icloud, and google drive, or transfer it through airdrop, then go to www.CornealAnalysis.com from any desktop computer and upload the photo.

Input the horizontal white to white measurement, and the central corneal power such ask SimK, normally taken from any tomographer or biometry.

Determine the actual white to white.

Locate the pupil (if you want its center to be the reference).

Measure the chord and angles of any point , both antickockwise and clockwise (measurements take into consideration the corneal curvature).

Measure the surface area of any lesion, like a pterygium, an epithelial defect, or ulcer, again with the output factoring in corneal curvature

For more advanced users, you can tinkle with the software and be creative:

You can determine angle kappa even from a autorefractometer image

You can, instead of the pupil, set the point of reference the center of the limbus, such as in chord alpha measurement

You can locate a point on the cornea in reference to the pupil, then pin the corneal vertex based on previous information from tomography, then save the image and reload it into the software and locate the point of interest as referenced to the vertex, or use this very point as the center of measurements. This is typically useful in PTK treatments or wavefront-guided/topography guided treatments with planned decentration.

Disclaimer

CornealAnalysis.com is merely a tool to help the clinician better assess a clinical situation and cannot replace your clinical judgement. The authors take no responsibility in whatever clinical consequence that might ensue where this software is used.

HELP

CONTACT

Contact us

CONTACT

HAZE

Haze is calculated by averaging pixel intensity values provided that they fall within a certain color range. Images are equalized for light intensity to minimize differences due to dissimilar lighting conditions.

For best results, use the same photography method to compare different haze cases. Abstain from calculating haze in eyes applied with fluorescein.

Make sure to correctly delineate the pupil with the white circle and the limbus with the blue circle for optimal calculations.
